27.1 Mobile Client Rebranding

This section includes the following information:

27.1.1 Modifying the Image Resources for the Mobile Clients

The NetIQ Cloud Manager documentation Web site has some templates of image resources that you can download and use to customize your own rebranded images. You need to ensure the following:

  • When a graphic designer creates the new brand images, the image size, format, and filename must remain the same. The image resources can help the designer maintain these criteria.

  • When you are finished customizing the images to match your own branding, upload them to the Cloud Manager Application Server.

The mobile device automatically detects the presence of the new images and rebrands itself on launch.

Catalog of Sample Images for the Mobile Clients

The table below shows the images that are included in the resources.zip file.

IMPORTANT:These images are not shown in their correct scale. Please download the samples.


Description and Usage


  • 144 x 44 pixels

  • corporate logo layered on top of product at main menu screen


  • 288 x 88 pixels

  • corporate logo layered on top of iPad work area at main menu


  • 27 x 27 pixels

  • iPad


  • 54 x 54 pixels

  • iPhone


  • 27 x 27 pixels

  • iPad


  • 54 x 54 pixels

  • iPhone


  • 320 x 76 pixels

  • iPhone top banner at main menu


  • 640 x 152 pixels

  • iPad top banner at main menu


  • 320 x 173 pixels

  • iPhone top banner at login


  • 640 x 376 pixels

  • iPad top banner at login


  • 72 x 22 pixels

  • corporate logo layered on top of iPad work area at login


  • 144 x 44 pixels

  • corporate logo layered on top of iPhone work area at login


  • 24 x 24 pixels

  • product logo layered with functional screens on iPhone


  • 48 X 48 pixels

  • product logo layered with functional screens on iPad


  • 256 x 256 pixels

  • watermarked product logo displayed on iPad login


  • 512 x 512 pixels

  • watermarked product log displayed on iPhone login

27.1.2 Setting Up Automatic Rebranding for the Mobile Clients

The Cloud Manager installation configuration automatically configures the Cloud Manager Application Server to serve up files from /var/opt/netiq/cloudmanager/webres and /var/opt/netiq/cloudmanager/webres/mobile.

Use the following steps to finish the setup of the rebranding feature after the initial Cloud Manager Application Server installation:

  1. Copy the proprietary images you want to use to rebrand the mobile clients to /var/opt/netiq/cloudmanager/webres/mobile.

  2. Restart Cloud Manager services (making sure to clear the cache) using the following command:

    /etc/init.d/netiq-cloudmanager reload

  3. Make sure you can access one of the rebranded files via a Web browser. For example, login.png:

    https://<server>:8183/resources/mobile/login.png

    NOTE:When you reference Cloud Manager files from a browser, the files must be referenced explicitly. For example, if you have a file called acme.png in a webres/mobile folder (/var/opt/netiq/cloudmanager/webres/mobile/acme.png), you cannot see it in a folder listing. For example, the following does not work:

    http://<server_name>:<port>/resources/mobile

    Instead, you need to access the file directly:

    http://<server_name>:<port>/resources/mobile/acme.png
